A Banded V-Belt Cross References

A section Banded V-belts consist of multiple individual V-belts that are joined together by a fabric top band. This construction creates a single belt unit that enhances stability and load distribution across the belt width, making it particularly suitable for applications with high shock loads, vertical shafts, or pulley misalignment. The A in the banded A-series V-belts refers to the belt's profile, indicating its cross-sectional dimensions, which are standard within the industry for this type.

The primary advantage of banded V-belts is their ability to minimize vibration and prevent the belts from twisting or turning over on the pulleys, which is especially valuable in heavy-duty applications. This configuration allows for smoother operation, increased belt life, and reduced maintenance requirements. Banded V-belts are used in a variety of industries, including agriculture, mining, and construction, where reliable and efficient power transmission is critical. Their robust design ensures consistent performance even under challenging conditions, making them a preferred choice for drives that demand high levels of reliability and durability.

*Please note that as an Amazon Associate a commission is earned from qualifying purchases. Some links on this page will direct you to Amazon.

Classical A Banded Belt Cross Reference Charts

A series banded belts, also known as A section V-belts, are commonly used in industrial and automotive applications. The dimensions for A series banded belts generally include the width, thickness, and length. Here's a breakdown of these standard dimensions:

Width: The width of an A series banded belt is typically 0.5 inches (about 13 mm).

Thickness: The thickness of these belts is usually about 0.31 inches (approximately 8 mm).

Length: The length of A series banded belts can vary significantly depending on the application. It is measured as the outer circumference of the belt and is typically specified in inches or millimeters. The length can range from short sizes suitable for compact machinery to very long lengths used in larger industrial equipment.
